Fluke 279 FC True-rms Thermal Multimeter
Product overview: Fluke 279 FC True-rms Thermal Multimeter
Find, repair, validate, and report electrical issues quickly
Locate the problem immediately
Thermal imaging multimeters are a first-line troubleshooting tool for electrical equipment that can check hot spots on high-voltage equipment and transformers, and detect heating of fuses, wires, insulators, connectors, splices and switches. Scanning with the 279 FC’s thermal imager reveals many electrical issues rapidly and from a safe distance. By combining two tools into one, the thermal multimeter lightens the load and increases productivity.
Expanded functionality
Compatible with iFlex® (a flexible current clamp) to expand your measurement capabilities and get into tight, hard to reach spaces for current measurement (up to 2500 A AC). The large full-color LCD screen makes for easier and clearer viewing of images and readings. The 10 hour+ rechargeable battery keeps you going all day long under normal conditions.
With built-in Fluke Connect®, transmit results wirelessly to a smartphone and save time on reporting to validate work is complete. Troubleshoot better by instantly trending and monitoring measurements live on your smartphone screen. Create and email reports right from the field.
Specifications: Fluke 279 FC True-rms Thermal Multimeter
| DMM | |
| Basic dc accuracy | 0.09% |
| Bandwidth | 1% 45 Hz to 65 Hz, full time low pass filter |
| Voltage | ac/dc 1000 V |
| Current ac | 2500 A with included iFlex Flexible Current Probe |
| Resistance | 50 MΩ |
| Frequency | 100 kHz |
| Capacitance | 9,999 µF |
| Continuity with beeper | Yes |
| Diode test | Yes |
| Min/Max recording | Yes |
| Display Hold | Yes |
| Infrared camera | |
| Infrared resolution | 102 x 77 |
| Image capture frequency | 8 Hz |
| Field of View | 36° (w) x 27° (h) |
| NETD | ≤200 mK |
| Infrared spectral band | 7.5 to 14 microns |
| Center point | Yes (with center point temp) |
| Focus mechanism | Fixed focus |
| Temperature Range (selectable °C and °F) | -10 °C to 200 °C (14 °F to 392 °F) Accuracy: ±5 °C (9 °F) or (±5% as tested) |
| Emissivity | 0.95 fixed |
| Background compensation | 20 °C fixed |
| Memory storage | Approximately 100 images (internal) |
| File format | Non-radiometric .is2 |
| General specifications | |
| Battery type | Rechargeable lithium ion battery (charge time: 4.5 hours) |
| Operating temperature | -10 °C to 50 °C (14 °F to 122 °F) |
| Storage temperature | -20 ºC to 60 ºC (-4 °F to 140 °F) |
| Relative humidity | 0% to 90% (0 °C to 35 °C) (32 °F to 95 °F) 0% to 75% (35 °C to 40 °C) (95 °F to 104 °F) 0% to 45% (40 °C to 50 °C) (104 °F to 122 °F) |
| Altitude | 2,000 meters (6,561 feet) |
| Temperature coefficient | Add 0.1 x specified accuracy for each °C above 28 °C or below 18 °C (°F above 82 °F or below 64° F) |
| Ingress Protection | (IP) IP40 (non-operating) |
| Wireless frequency | 2.4 GHz ISM Band, 20 meter range |
| Certifications | CE, CSA, FCC |
| Safety compliance | IEC 61010-1: Pollution degree 2; IEC 61010-2-033: CAT III 1000 V/CAT IV 600 V |
| EMC | EN 61326-1:2012 |
| Size | 215.9 x 93.9 x 57.1 mm (8.5 x 3.7 x 2.25 in) |
| Weight | 0.793 kg (1.75 lb) |
| Warranty | Limited three-year warranty |
Models: Fluke 279 FC True-rms Thermal Multimeter
Includes:
- 279 FC TRMS Thermal Multimeter
- 45.72 cm (18 in) iFlex Flexible Current Probe
- (1 pair) TL175 Test Leads
- Rechargeable Lithium Ion Battery and Charger
- Soft Carrying Case
- Hanging strap
- 279 FC True-rms Thermal Multimeter
- 45.72 cm (18 in) iFlex Flexible Current Probe
- (1 pair) TL175 Test Leads
- (2) Rechargeable Lithium Ion Batteries and Charger
- Soft Carrying Case
- Hanging strap
If you need any further information about this product, feel free to contact us!
