| Battery type |
VRLA |
| Minimum flammability rating |
HB |
| Number of blocks |
32–40 |
| Battery shelves |
4 shelves sized 657 x 767 mm |
| Maximum weight per shelf (kg) |
300 |
| Maximum weight per cabinet (kg) |
1200 |
| Height between battery shelves (mm) |
340 |
| Maximum battery height including battery terminals (mm) |
240 |
| Recommended Cable Sizes |
10 kVA |
15kVA |
20kVA |
30 kVA |
40 kVA |
| Battery (mm² |
8 |
8 |
25 |
25 |
35 |
| PE (mm²) |
6 |
6 |
10 |
16 |
16 |
| Torque |
| Bolt size |
Torque |
| M6 |
5 Nm (3.69 lb-ft) |
| M10 |
30 Nm (22 lb-ft) |
| Empty Classic Battery Cabinet Weight and Dimensions |
Weight kg |
Height mm |
Width mm |
Depth mm |
| Empty classic battery cabinet |
190 |
1970 |
700 |
850 |
