Specifications Easy UPS 3S 15 kVA 400 V 3:3 UPS for internal batteries
+ Main
| Main Input Voltage | 400 V 3 phases |
|---|---|
| Other Input Voltage | 380 V 415 V |
| Main Output Voltage | 400 V 3 phases |
| Other Output Voltage | 380 V 415 V |
| rated power in W | 15 kW |
| Rated power in VA | 15 kVA |
| Provided equipment | Dust filter Installation guide |
+ Batteries & Runtime
| Battery type | VRLA |
|---|---|
| Battery voltage | 240 V |
| Maximum short-circuit current | 10 kA |
| Number of battery filled slots | 0 |
| Number of battery free slots | 3 |
+ Physical
| Colour | White (RAL 9003) |
|---|---|
| Height | 140 cm |
| Width | 38 cm |
| Depth | 92.8 cm |
| Product weight | 112 kg |
| USB compatible | Yes |
+ Input
| Maximum input current | 28 A |
|---|---|
| Input harmonic distortion | Less than 3 % for full load |
| Load power factor | 0.9 leading to 0.9 lagging |
| Input Power Factor at Full Load | 0.99 |
| Input voltage limits | 304…477 V |
| Network frequency | 45…65 Hz |
+ Output
| Maximum configurable power in VA | 15 kVA |
|---|---|
| Maximum configurable power in W | 15 kW |
| Output frequency | 50 Hz sync to mains 60 Hz sync to mains |
| Harmonic distortion | Less than 3 % |
| Output harmonic distortion | < 3% linear load |
| Output voltage tolerance | +/- 1.5 % |
| UPS type | Double conversion online |
+ Conformance
| Product certifications | CE EAC RCM |
|---|
+ Environmental
| Ambient air temperature for operation | 0…40 °C |
|---|---|
| Relative humidity | 0…95 % non-condensing |
| Operating altitude | 0…3333 ft |
| Ambient air temperature for storage | -15…40 °C |
| Storage Relative Humidity | 0…95 % non-condensing |
| Storage altitude | 0.00…15240.00 m |
| Acoustic level | 60 dBA |
| Heat dissipation | 852 Btu/h |
| IP degree of protection | IP20 |
+ Packing Units
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 164 cm |
| Package 1 Width | 101.4 cm |
| Package 1 Length | 56.3 cm |
| Package 1 Weight | 145 kg |
+ Contractual warranty
| Warranty | 1 year on-site repair or replace with factory authorized Start-Up |
|---|
+ Description:
High-efficiency 3-phase UPS that features advanced product features, competitive specifications, and robust electrical design, making business continuity easy in the data center or electrical room. This is an exceptionally easy-to-install, operate, maintain, and service 15 kVA UPS, ideal for small and medium businesses. Includes dust filter and conformance-coated boards for harsh environments. This UPS is for internal batteries but is supplied without batteries, so you can easily customize the battery runtime.
