Kanomax 6710: Tabmaster Airflow Capture Hood



Key Features

  • 23 to 2500 CFM (40 to 4250 m3/h) range
  • Simultaneously measures and displays air flow, temperature and humidity
  • Displays the direction of the airflow as well as the velocity
  • Store up to 3,000 measurements
  • Advanced storage feature allows you to store multiple measurements under a single ID number

specifications Kanomax 6710: Tabmaster Airflow Capture Hood

  • Main Unit Specifications

— Airflow

Range: 23 to 2500 CFM (40 to 4250 m3/h)
Accuracy: +/-3% of READING +/- 8m3/h (>85m3/h)
Resolution: 1 m3/h
— Temperature
Range: 32 to 122°F (0 to 50°C)
Accuracy: +/- 0.5°C
Resolution: 0.1°C
— Humidity
Range: 0 to 100 %RH
Accuracy: +/- 3.0 %RH (10 to 90 %RH)
Resolution: 0.1 %RH
  • General Specifications Kanomax 6710

Standard Hood Dimensions: 2′ x 2′ (610x610mm)

Available Hood Dimensions:
2′ x 4′ (610x1220mm)1′ x 4′ (305x1220mm)
3′ x 3′ (915x915mm)
3′ x 2′ (915x610mm)
20″x 20″ (500mm x 500mm)
2′ x 2′ with Straighteners
Datalogging: Up to 3,000 Measurements
Power Supply: 4 x AA batteries or OPTIONAL AC Adapter
Weight & Dimensions: 7.9 lbs (3.6 kg), Main body: 24″ x 24″ x 37″, Micromanometer: 3.4″ x 7.4″ x 1.6″
Standards: CE-mark
Warranty: 1 year
What’s included: Meter, standard hood (2 x 2ft), PC communication cable, data processing software, operational manual, carrying case, calibration certificate

Introduction Kanomax 6710

Whether you need to test a newly installed HVAC system for initial functionality, re-test a building’s HVAC after it undergoes significant constructional changes or regular seasonal change check-ups, the TABmaster Flow Hood Model 6710 needs to be in your equipment arsenal.

The unit has some defining characteristics that put it into the running for the best choice among professionals who actually operate TAB instruments in the field on a day-to-day basis.

Features

– 23 to 2500 CFM (40 to 4250 m3/h) range
– Simultaneously measures and displays airflow, temperature, and humidity
– Displays the direction of the airflow as well as the velocity
– Kanomax 6710 stores up to 3,000 measurements
– Advanced storage feature allows you to store multiple measurements under a single ID number
– This is the perfect tool for accurate supply and return airflow measurements
– Our optional interchangeable hoods make it a snap to sample the air for any duct size
– The unit is lightweight and easy to handle
– Simultaneously measures and displays airflow, temperature, and humidity
– Motorized tilt on the meter to allow for meter angle adjustment
– A multi-functional instrument that measures airflow and pressure readings
– Air volumetric flow measurements through registers, diffusers, and grilles
– Displays Air velocity direction and measurement in full color for clear, easy viewing
– HERS (Home Energy Rating System) approved testing instrument
– NIST TRACEABLE CALIBRATION CERTIFICATE*
*NIST TRACEABLE CALIBRATIONS are performed at our facility in ANDOVER, NJ.
