SLS 1500 Syringe Liquid Particle Sampler

Introduction Syringe Liquid Particle Sampler PMS SLS 1500

The PMS SLS 1500 Syringe Liquid Particle Sampler from Particle Measuring Systems uses a precision syringe and simple flow-path for delivering chemical samples from a sample vessel or chemical container, directly to the particle sensor. It is ideal for applications where precise, small-volume particle batch sampling is required, where the sampler device cannot contribute contamination to the chemical sample.



The system consists of a selectable syringe for either corrosive or non-corrosive liquids, a selectable particle counter for different sizing sensitivities, and batch-sampling software.



Particle Measuring Systems (PMS) sets the standard for cleanroom contamination monitoring. With more than 60 patents, PMS create the technology that enables you to make fact-based decisions, improve process yield and comply with changing regulatory requirements.

Benefits Syringe Liquid Particle Sampler SLS 1500

Cost-Effective

• Small sample volume minimizes waste of expensive product
• Automated system saves time and money
• Compatibility with both corrosive and non-corrosive liquids

Easy-to-Use

• Menu-driven data collection
• Recipes can be created and retrieved for repeatable system operation with different operators
• Password security maintains system integrity

Versatile

• Ability to support a wide range of applications
• Programmable particle size thresholds
• Extremely accurate measurements

Syringe size	1, 5, 10 (standard) 25 ml
Sampling mode	Vacuum
Minimum sample size	0.4 ml, 20 ml/min
Wetted surface materials	Glass, Teflon® (all Teflon optional)
Power	100 – 240 V, 50 – 60Hz
Sample volume	Adjustable using software interface
Maximum pressure	25 psi
Dimensions (l, w, h)	38.1 x 22.0 x 43.4 cm, including particle counter
Weight	13.6 kg including particle counter
Environment Temperature	10 – 30 ºC
Humidity	Non-condensing
Particle Sensor	LiQuilaz S05
Particle Size range	0.5 to 20 μm
Channels	15
Flow rate	20 ml/min
Sampled %	100%
Maximum concentration	10,000 particles/ml
Zero count	< 50 counts/l
Sample temperature	50 – 122 °F (10 – 50 ºC)
Calibration	Materials used are traceable to US National Institute of Standards and Technology (NIST) and Japanese Institute of Standards (JIS).
Software	SamplerSight

Applications

• Small volume chemical quality assurance
• Parts cleanliness testing
• Laboratory water sampling
• Pharmaceutical testing for USP compliance
• Industries: semiconductor, pharmaceutical, data storage, medical, aerospace, automotive, hydraulic oils
