GW Instek PSS-3203 D.C Power Supply (Programmable Linear)



Features

  • Digitized Programmable Interface
  • High Resolution 10mV, 1mA
  • High Stability, Low Drift
  • Over-Voltage, Over-Current, Over Temperature Protection
  • Intelligent Fan Control (Changes by Output Power)

SPECIFICATIONS GW Instek PSS-3203 D.C Power Supply

OUTPUT

Voltage: 0~32V

Current: 0~3A

OVP: 0~33V

LOAD REGULATION

Voltage: < 3mV ( < 5mV rating current > 3A)

Current: < 3mA ( < 5mA rating current > 3A )

LINE REGULATION

Voltage < 3mV

Current < 3mA

RESOLUTION

Voltage 10mV

Current 1mA ( 2mA, rating current >3A )

OVP 10mV

PROGRAM ACCURACY (25±5° C)

Voltage < 0.05% + 20mV

Current < 0.1% + 5mA (10mA, rating current> 3A)

OVP < 0.05% + 20mV

RIPPLE & NOISE (20Hz ~ 20MHz)

Voltage

Ripple≦1mVrms / 3mVp-p

Noise≦2mVrms / 30mVp-p

Current < 3mArms ( < 5mArms, rating current > 3A )

TEMPERATURE COEFFICIENT (0~40° C )

Voltage < 100ppm + 3mV C

urrent < 100ppm + 3mA

READBACK RESOLUTION

Voltage 10mV

Current 1mA ( 2mA, rating current > 3A )

READBACK ACCURACY (25±5° C)

Voltage < 0.05% + 10mV

Current < 0.1% + 5mA (10mA rating current > 3A)

READBACK TEMPERATURE COEFFICIENT

Voltage < 100ppm + 10mV

Current < 100ppm + 5mA ( + 10mA rating current > 3A )

RESPONSE TIME

Voltage Up 10%~90% < 100mS

Voltage Down 90%~10% < 100mS ( ≧10% rating load )

DRIFT

Voltage < 100ppm + 10mV

Current < 150ppm + 10mA

INTERFACE

Standard : RS-232C

Option : GPIB (IEEE488.2)

POWER SOURCE

AC100V/120V/220V±10%, 230V (+10%~-6%), 50/60Hz

ACCESSORIES

User manual x 1

Power cord x 1

Test lead GTL-105 x 1 [or European

Test Lead GTL-203 x 1]

DIMENSIONS & WEIGHT

108(W) x 140(H) x 315(D)mm Approx. 4.8kg

Introduction GW Instek PSS-3203 D.C Power Supply

The PSS-Series (Model GW Instek PSS-3203) is single output, 96W or 100W, programmable linear DC power supplies. OVP, OCP, and OTP protect the PSS series and their loads from unexpected conditions. The LCD panel simultaneously displays output and other parameters; the regulated cooling fan ensures low noise for comfortable operation. RS232C and GPIB interfaces, SCPI command sets, and LABVIEW drivers make remote control and ATE software development easier. (Note: only either RS-232C or GPIB can be installed) The compact PSS series is suitable for any high resolution bench-top or rack mount application.

Features GW Instek PSS-3203

  • Digitized Programmable Interface
  • High Resolution 10mV, 1mA
  • High Stability, Low Drift
  • Over-Voltage, Over-Current, Over Temperature Protection
  • Intelligent Fan Control (Changes by Output Power)
  • Built-in Buzzer Alarm
  • Labview Driver
  • Standard Interface: RS-232C
  • Optional Interface: GPIB (IEEE-488.2)
  • Optional European Jack Type Terminal

GW Instek  Brand

Good Will Instrument Co., Ltd (acronym is GW Instek)  is a leading manufacturer of electrical test & measurement instruments in Taiwan. GW Instek is founded in 1975 and began as a manufacturer of power supplies and quickly expanded into the development of high precision electronic test and measurement instruments. After decades of experience in the test and measurement industry, GW Instek has grown to become one of the important manufacturers and developers of test and measurement instruments worldwide.
