GW Instek GPR-3060D D.C Power Supply (Linear)

SPECIFICATIONS GW Instek GPR-3060D D.C Power Supply

DC OUTPUT

Output Volts (V): 0 ~ 30

Output Amps (A): 0 ~ 6

CONSTANT VOLTAGE OPERATION

+ Regulation:

Line regulation: < 0.01% + 3mV

Load regulation: <0.01% + 5mV (<10A)

Load regulation: < 0.02% + 5mV (>10A)

+ Ripple & Noise:

< 1mVrms (5Hz ~ 1MHz)

+ Recovery Time:

< 100μS ( 50% load change, minimum load 0.5A )

+ Output range:

0 to rating voltage continuously adjustable

CONSTANT CURRENT OPERATION

+ Regulation:

Line regulation: < 0.2% + 3mA

Load regulation: <0.2% + 3mA

+ Ripple Current: < 3mArms

+ Output Range: 0 to rating current continuously adjustable

METER

Type: 3 1/2 Digits 0.5″ LED Display

Accuracy: ±( 0.5% of rdg + 2 digits )

INSULATION

Chassis and Terminal: 20MΩ or above (DC 500V)

Chassis and AC Cord: 30MΩ or above (DC 500V)

POWER SOURCE

AC 100V/120V/220V/240V±10%, 50/60Hz

ACCESSORIES

User manual x 1

Power cord x 1

Test Lead GTL-104 x 1

DIMENSIONS & WEIGHT

255(W) x 145(H) x 335(D)mm

Approx. 11.5kg

Introduction GW Instek GPR-3060D D.C Power Supply

GW Instek GPR-3060D is single output, 180W, linear DC power supplies, featuring all the same functions as the GPR-H Series but for lower power demands. Like the GPR-H Series, the GW Instek GPR-3060D is suitable for high-end precision bench top applications. Low load and line regulation for both constant voltage and constant current mode ensure reliable, predictable output. Overload and reverse polarity protection as well as internal selection for dynamic or constant load are standard.
