Fluke 404E/406E/405/408/410 Laser Distance Meter
Product overview
These Laser Distance Meters have the Fluke durability and quality you expect. The simple design and easy-to-use button operation allow you to operate with one hand, minimize time spent measuring and maximize the reliability of measurements.
Specifications: Fluke 404E/406E/405/408/410 Laser Distance Meter
| Model | Fluke 404E | Fluke 406E | Fluke 405 | Fluke 408 | Fluke 410 |
|---|---|---|---|---|---|
| Specifications | |||||
| Range | 0.2 to 40 m | 0.2 to 60 m | 0.2 to 50 m | 0.2 to 80 m | 0.2 to 100 m |
| Accuracy* in favorable condition** |
±(2.0mm+5×10-5D) | ±(2.0mm+5×10-5D) | |||
| Accuracy in unfavorable condition*** |
±(3.0mm+29×10-5D) | ±(3.0mm+29×10-5D) | |||
| Angle accuracy | ±(0.3°+0.1°+0.01*A), A is up to ±45° in each quadrant | ||||
| Angel measurement method | Electronic | ||||
| Measurement unit | m / ft / in / ft+in | ||||
| Display | 1.6 inch, segment alphanumeric display | 2.0-inch positive display | |||
| * Temperature for specified accuracy: 25°C
** Favorable conditions: white and diffuse reflection objects (white painted walls) ,low background illumination and moderate temperature *** Unfavorable conditions: objects with low or high reflectivity, high background illumination or the temperature is at the upper or lower limit of the specified temperature range |
|||||
| Measurements | |||||
| Single measurement | ● | ● | ● | ● | ● |
| Continuous measurement | ● | ● | ● | ● | ● |
| Area measurement | ● | ● | ● | ● | ● |
| Volume measurement | ● | ● | ● | ● | ● |
| Auto Leveling | ● | ● | ● | ● | ● |
| Auto Vertical | ● | ● | ● | ● | ● |
| Pythagoras 1 | ● | ● | ● | ● | ● |
| Pythagoras 2 | ● | ● | ● | ● | ● |
| Plus-minus method | ● | ● | ● | ● | ● |
| Measurement reference | Front / Back | Front / Tripod hole / Back / Extender | |||
| Auto-off | 3 minutes after inactivity | 3 minutes after inactivity | |||
| History measurement data | 30 sets | 100 sets | |||
| Time-delay measurement | ● | ● | ● | ||
| Auto calibration | ● | ● | ● | ||
| Side button | ● | ● | ● | ||
| Extender | ● | ● | ● | ||
| General | |||||
| Laser class | Class 2 | ||||
| Laser type | 630 to 670nm, <1mW | ||||
| Battery life | up to 5000 measurements (single measurement) | up to 3500 measurements (single measurement) | |||
| Operating temperature | 0 C° to 40 C° | ||||
| Storage temperature | -10 C° to 60 C° | ||||
| Ingress protection | IP54 | IP65 | |||
| Drop test | 1 m | 1 m | |||
| Size | 50 mm × 115mm × 29mm | 52 mm × 116mm × 28mm | |||
| Weight | 100g | 110g | |||
| Certification | |||||
| Laser certification | IEC 60825-1: Class 2, 635 nm, <1 mW CPA, CE |
||||
| Electrical certification | IEC 61010-1: Pollution Degree 2 EMC： IEC 61326-1: Industrial Electromagnetic Environment CISPR 11: Group 1, Class A |
||||
| Packaging and accessories | |||||
| Packaging box | Folding box | Folding box | Full telescope | Full telescope | Full telescope |
| User manual | √ | √ | √ | √ | √ |
| Vinyl carrying pouch | √ | √ | √ | √ | √ |
| Battery | 2 AAA alkaline cells | 2 AAA alkaline cells | 2 AAA NiMH rechargeable cells | 2 AAA NiMH rechargeable cells | 2 AAA NiMH rechargeable cells |
| Qualification certificate | √ | √ | √ | √ | √ |
| Lanyard | √ | √ | √ | ||
| Charging cable | Type-C cable, 0.5m | Type-C cable, 0.5m | Type-C cable, 0.5m | ||
